Multi-Function Airflow Monitor LC013 industrial air flow meter sensor
Produktbeschreibung
Multi-Function Airflow Monitor LC013 industrial air flow meter sensor
Contact type reed / magnet contact
Normally closed (NC) switch contact open when air is flowing
Normally open (NO) switch contact closed when air is flowing
Max. switching voltage NC: 240VDC (UL), 240V AC/DC (VDE) / NO: 60VDC
Max. switching current NC: DC 500mA / NO: DC 170mA
Max. switching capacity 10W (resistive load)
Switching threshold of airflow velocity > 2.5m/s (hysteresis: > 1m/s)
Max. airflow velocity 50m/s
Contact resistance < 370mOhm (with wire)
Max. air humidity 70% RH (not precipitating)
Service life > 100 000 cycles
Connection 2 x single strand AWG 28, length 500mm, tip of stranded wire 5mm stripped and tinned (NC: black, NO: blue)
Mounting alternatively integrated in protective grille (see table), mounting clamp or mounting clip
Casing plastic according to UL94-HB, black
Fitting position bidirectional tab perpendicular to airflow
Operating/Storage temperature -20 to +50°C (-4 to +122°F) / -20 to +80°C (-4 to +176°F)
Protection type IP20
Approvals VDE + UL File No. E250507
Note The product of switching voltage and switching current must not exceed 10W. The max. voltage and max. current must not be exceeded, not even short-term (voltage/current peaks). The resulting voltage and current peaks of inductive or capacitive loads must be restricted by a contact protection circuit.
Description Art. No. (NC) Art. No. (NO) Dimensions Weight (approx.)
Airflow monitor with mounting clamp and mounting clip LC 013 01300.0-00 01300.1-00 34 x 17.5 x 7.5mm 5g
Airflow integrated in protective grille (plastic) LCF 013 01301.0-00 01301.1-00 80 x 88 x 10.5mm 20g
Airflow integrated in protective grille (plastic) LCF 013 01302.0-00 01302.1-00 92 x 92 x 10mm 20g
Airflow integrated in protective grille (plastic) LCF 013 01303.0-00 01303.1-00 120 x 120 x 10mm 30g
Airflow monitor with mounting clamp and mounting clip LC 013 01300.0-00 01300.1-00 34 x 17.5 x 7.5mm 5g
Airflow integrated in protective grille (plastic) LCF 013 01301.0-00 01301.1-00 80 x 88 x 10.5mm 20g
Airflow integrated in protective grille (plastic) LCF 013 01302.0-00 01302.1-00 92 x 92 x 10mm 20g
Airflow integrated in protective grille (plastic) LCF 013 01303.0-00 01303.1-00 120 x 120 x 10mm 30g
Part#: LC 013 LCF 013 both Version in stock NO and NC
Condition/Zustand: new/neu
